SAM FPM 155 Fully Automatic Double Unit Filling and Packaging Line (1Kg-2Kg-5Kg)

Fully Automatic Filling and Packing Line with Double Filling Unit is the line that automatically takes, fills and packs powdery and granular products in the same machine with flat-bottom ready-made paper packages. The filled packages move towards the bag closing machine on the band. In the bag closing machine, the excess paper is cut, the first fold is made, the last fold is made with hot glue and it comes out of the machine with the mouth closed. The dates of the packages coming out of the bag closing machine are automatically discarded and the packages move towards the bundle shrink machine. In the shrink machine, the packages are grouped and shrinked.

  • Sensibility: The margin of error in the filling for 1kg is ± 0.5% (5 per thousand) and the working waste is below 2%.
  • Guarantee: It is guaranteed for 2 years in Türkiye and 1 year abroad.
  • Capacity: In 1 kg packaging: 38-40 bags/minute
    In 2 kg packaging: 24-26 bags/min
    In 5 kg packaging: 10-12 bags/min
  • Electric: It works with 380 V, 3 Phase, 50 HZ.
  • As a facility, it consists of sealing, hot glue, inkjet printer, clustering-shrinking machines and other parts according to demand.

Technicial Specifications

  • * Screw and volumetric system is used for filling powdery and granular products such as flour and semolina.
    * Fills 1Kg, 2Kg and 5Kg flat-bottom, ready-made paper packages.
    * All control is done from touch PLC screen.
    * There is automatic lubrication in the whole system.
    * There is a dust suction system on the filling system.
    * There is a stainless silo of 200 Kg for powdery products and 50 Kg for filling granular products on the machine.
    * Metal surfaces are coated against corrosion before painting.
    * Machine paint is durable static paint.
    * All surfaces in contact with the product to be packaged are stainless.
    * Metal surfaces are nickel plated and blackened, stainless.
    * There is a speed-adjustable vibration system.
    * Electrical materials: Schneider (France)
    * Pneumatic materials: Festo (Germany)
    * Vacuum holders and suction cups: Festo (Germany)
    * Gearboxes: Yılmaz Redüktör (Türkiye)
    * PLC control system: ABB (Switzerland)
    * Transport and drag belts: Sieling (Germany)

Technical Drawing

Way of Working
